Fanless Mini PC P05B with 5th Gen Core i3 i5 i7 Processor

Fanless Mini PC P05B with 5th Gen Core i3 i5 i7 Processor

Product Name Fanless Mini PC P05B with 5th Gen Core i3 i5 i7 Processor
Item NO. P05B-D3
Weight 2.6 kg = 5.7320 lb = 91.7123 oz
Category Fanless Mini PC
Tag fanless mini pc , mini pc , fanless pc , hystou
Brand HYSTOU
Creation Time 2020-07-03





The 5th generation Intel Core processor delivers a dramatic boost in graphics and CPU performance, driving Internet of Things (IoT) innovation while maintaining compatibility with previous generations. Compare to 4th generation Intel Core processor, it get 35% more transistors, 22% better in 3D graphics, 50% faster in video conversion, etc.

Main advantages of this mini pc:



[Memory expansion] Equipped with 204 Pin DDR3L RAM. The memory can be expanded up to 128 GB with a micro SD card and up to 2 TB with a standard 2.5-inch SATA HDD / SSD . You can also plug in a 2TB mobile hard drive box via the USB 3.0 interface.

[Faster Running Speed] Equipped with Intel Broadwell Core processor , pre-installed Windows 10 Pro (64-bit). Powerful hardware makes it run more stable. Creates smoothly experience for your visually home entertainment, streaming video, web browsing, gaming and work.

[No noise & portability] The fanless design of this mini PC can save power and achieve zero noise. The unique shell design and energy-saving components make cooling faster and more efficient. We presented a mini console stand in the package, which can save a lot of space.
[Memory & Storage] Memory types: Dual 204 Pin DDR3L SO-DIMM Socket. Storage:1 x SATA3.0 for 2.5 inch HDD/SSD,2 x mSATA slot.
[Dual Screen Display]Built with 2 x HDMI (4K) port, seamlessly connecting two monitors. With integrated Intel HD graphic to enjoy 4K Web surfing, video playback, watching TV, home theater, enjoy the entertainment with your family. Support 2.4G/5.8G Band WiFi.
[Low-carbon Green] TDP only 15W, very economical, saving a lot energy every year, low consumption but with a very amazing performance.

[Rich and diverse ports] 4 x USB 3.0 port, 4 x USB 2.0 port,1 x SD card reader slot,1 x Optical audio port,1 x 3.5mm MIC in & SPK out,1 x Optical audio port,1 x 3.5mm MIC in & SPK out,2 x RJ45 Lan, RTL8168/8111/8112 Gigabit Ethernet Controller,2.4G&5G 300Mbps & Bluetooth,2 x external Wi-Fi antennas.



Onboard Intel broadwell 5th generation processor. Available processors:

1. Intel® Core™ i7-5500U Processor (4M Cache, up to 3.0 GHz)
2. Intel® Core™ i5-5200U Processor (3M Cache, up to 2.70 GHz)
3. Intel® Core™ i3-5005U Processor (3M Cache, up to 2.0 GHz)



  • Technical Specifications

    Processor

    CPU

    Intel Broadwell Core i7-5500U (4M Cache, 2 Cores 4 Threads, Base Frequency 2.40 GHz Turbo Frequency 3.0 GHz)

    Intel Broadwell Core i5-5200U (3M Cache, 2 Cores 4 Threads, Base Frequency 2.20 GHz Turbo  Frequency 2.70 GHz)

    Intel Broadwell Core i3-5005U (3M Cache, 2 Cores 4 Threads, Base Frequency 2.0 GHz)

    Chipset

    Intel 5th Generation Intel Core SOC Chipset

    TDP

    15W

    CPU Lithography

    14 nm

    Memory Specifications

    Max Memory Size

    16GB

    Memory Types

    204 pin DDR3L SO-DIMMs

    Memory Channels

    Dual Channels

    ECC Memory

    Don’t support

    Storage Specification

    m.2 SSD

    No

    SATA

    1 x SATA3.0 for 2.5 inch HDD/SSD

    mSATA

    2 x mSATA SSD

    Graphics

    Processor Graphics

    Intel HD Graphics 5500

    HDMI

    2 x HDMI (4K)

    Power Specification

    Power Adapter

    12V Power Input, supply 12V 5A power adapter within the package

    Auto Power On

    Support Auto Power On Function

    In & Out interfaces

    USB Port

    4 x USB 3.0 port, 4 x USB 2.0 port

    SD Card

    1 x SD card reader slot

    Audio

    1 x Optical audio port

    1 x 3.5mm MIC in & SPK out

    Video

    Dual HDMI 4K output

    Power Input

    12V In

    Switch

    1 x Power On/Off switch

    Lan Port

    2 x RJ45 Lan, RTL8168/8111/8112 Gigabit Ethernet Controller

    Wi-Fi

    2.4G&5G 300Mbps & Bluetooth

    2 x external Wi-Fi antennas

    Others

    System

    Support Windows 7/10, Linux

    Case Material

    Aluminum Alloy

    Dimension

    Mini PC size 224 x 185x50mm

    Package size 320 x 258 x 78mm

    Weight

    Gross weight 2.6 kg
